Suzuki Vitara (2015-Current) Slimline II Roof Rail Rack Kit
You Save 11% ($93.34)
All Front Runner Rack Kits contain installation instructions as well as all the components needed to mount the Slimline II Tray to your vehicle.NOTE: Your vehicle must be equipped with the factory/OEM roof rails in order to use this rack kit.This rack kit can be removed leaving your vehicles roof and roof rails in their original condition.For a stronger expedition grade cargo carrying solution, Front Runner may offer a specific Foot Rail System to mount the Rack Tray to your vehicle. Front Runner Foot Rail solutions can be installed by removing the factory roof rails or used if no factory roof rails are fitted.All Front Runner Racks are backed by a Limited Lifetime Warranty* *NOTE: This Roof Rack Kit will only work with the following the following models:GL 5MT / GL+5MT / GL+6AT / GL+5MT / AllGrip.It will NOT work with sunroof equipped models:GLX 6AT / GLX 5MT
KRSV002T - Suzuki Grand Vitara (2015-Current) Flush Rail Slimline II Roof Rack Kit - by Front Runner
2 x GOFR001 - Rail Foot Base (Pair) - by Front Runner 2 x GOFR014 - Flush Rail Outer Grips / No. 6 - by Front Runner 2 x GOFR031 - Flush Rail Inner Grips / B - by Front Runner 1 x RRSTA06 - Slimline II Tray - 1165mm(W) X 1156mm(L) - by Front Runner
Black epoxy powder-coated T6 aluminium 3CR12Stainless Steel
Approximate Installed Weight 19kg (43lbs)
The t-slots on the tops and bottoms of the rack tray slats and edge profiles accommodate standard 8mm bolts.
To determine the approximate height from your vehicleâ€™s roof to the top of your Slimline II Roof Rack, add the height of the Slimline II Tray (50mm/ 2") to the height of the Foot, Grab-on Foot or Strap-On Foot listed above.
If your Slimline II Roof Rack kit uses Legs, add the height of the Slimline II Tray (50mm/ 2") to the height of the Legs to determine the height of the rack from your vehicleâ€™s rain gutters.
If your Slimline II Roof Rack kit uses Foot Rails, add the height of the Slimline II Tray (50mm/ 2") to the height of the Foot Rails to determine the height of the rack from the crown (highest point) of the vehicles roof.
